Basic Info
Model No.: EX35U
Brand: Wenpeng
Origin: China
Certification: CE
Applicable Industry: Construction Works, Energy &Amp; Mining, Farms, Home Use, Other, Machinery Repair Shops, Building Material Shops
Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Place Of Origin: China
Status: New
Exercise: Crawler Excavator
Warranty Period: 1 Year
Engine Brand: Kubota
Mechanical Test Report: Provided
Video Factory Inspection: Provided
Operating Weight: 3.5ton
Bucket Capacity: 0.08m³
Power: 17.1/2200 kw/rpm
Digging Depth: 2824mm
Additional Info
Productivity: 100sets/month
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 100sets/month
Certificate: CE
Port: Qingdao
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW,DDP
Product Description
| Operating weight | kg | 3300 |
| With Cabin | kg | 3500 |
| Bucket capacity | m³ | 0.08 |
| Working device form | - | Backhoe |
| Fuel tank capacity | L | 33 |
| Engine Model | - | KUBOTA D1703 |
| Displacement | L | 1.647 |
| Engine power/rpm | kw/r | 17.1/2200 |
| Max. torque | N.m/r/min | 97.4/1500 |
| Engine oil capacity | L | 7 |
| Max. travel speed | km/h | 4.5 |
| Swing speed | rpm | 9 |
| Max. Grade ability | ° | 30° |
| Bucket digging force | kN | 29.5 |
| Bucket arm digging force | kN | 18.1 |
| Maximum tractive force | kN | 27.1 |
| Track Material | - | Rubber/Steel |
| Track Model | - | 300*52.5*84/300*101.6*43 |
| Crawler tension device | - | Butter oil cylinder |
| Ground pressure | kPa | 33.3 |
| Pump type | - | Piston pump |
| Pressure | MPa | 23MPa |
| Displacement | L | 99 |
| Rotary hydraulic motor | - | Piston motor |
| Walking hydraulic motor | - | Piston motor |
| Hydraulic manifold valve | - | Load Sensing Valves |
| Hydraulic oil tank capacity | L | 14.5 |
| Wheel base | mm | 1623 |
| Track length | mm | 2077 |
| Upper chassis ground clearance | mm | 295 |
| Counter weight turning radius | mm | 905 |
| Chassis width | mm | 1550 |
| Track width | mm | 300 |
| Rotary table ground-off height | mm | 515 |
| Transportation length | mm | 4561 |
| Total height | mm | 2539 |
| Bucket total width | mm | 665 |
| Max. digging radius on ground | mm | 4960 |
| Max. digging radius | mm | 4835 |
| Max. digging depth | mm | 2824 |
| Max. digging height | mm | 4600 |
| Max. dumping height | mm | 3200 |
| Maximum vertical digging depth | mm | 2196 |
| Minimum turning radius | mm | 1960 |
| Maximum Lift Of Dozer blade | mm | 358 |
| Maximum depth Of Dozer blade | mm | 323 |
| Boom right offset angle | ° | 49 |
| Boom left offset angle | ° | 49 |
