| Payment Type: | L/C,T/T |
|---|---|
| Incoterm: | FOB,CFR,CIF,EXW |
| Min. Order: | 1 Set/Sets |
Basic Info
Model No.: EX26
Brand: Wenpeng
Origin: China
Certification: CE
Applicable Industry: Manufacturing Plant, Building Material Shops, Farms, Home Use, Energy &Amp; Mining, Construction Works
Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts
Place Of Origin: China
Status: New
Exercise: Crawler Excavator
Warranty Period: 1 Year
Engine Brand: Kubota
Unique Selling Point: Epa Engine
Mechanical Test Report: Provided
Video Factory Inspection: Provided
Core Components: Pump, Engine, Motor
Additional Info
Productivity: 100sets/month
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 100sets/month
Certificate: CE
Port: Qingdao
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Product Description
| Operating weight | 2300 kg | |
| Bucket capacity | 0.068 m3 | |
| Working device form | Backhoe | |
| Fuel tank capacity | 20 L | |
| Engine | Model | Kubota D1105 |
| Displacement | 1.267 | |
| Engine power/rpm (kw/r(PS/rpm)) | 14/2200 | |
| Max.torque (N.m/r/min) | 71.5N.m @2200rpm | |
| Engine oil capacity | 3.4 L | |
| Speed/ Digging force | Max. travel speed km/h | 2-3.8 |
| Swing speed rpm | 9.5 | |
| Max.Grade ability | 30° | |
| Bucket digging force kN | 24 | |
| Bucket arm digging force kN | 14.8 | |
| Maximum tractive force kN | 23 | |
| Track Parameters | ||
| Track Material | rubber | |
| Track Model | 230*48*82 | |
| Crawler tension device | Butter oil cylinder | |
| Ground pressure kPa | 26.5 | |
| Hydraulic System | ||
| Pump type | Piston pump | |
| Pressure Mpa | 24.5MPa | |
| Displacement | 61.6L/min | |
| Rotary hydraulic motor | Piston motor | |
| Walking hydraulic motor | Piston motor | |
| Hydraulic manifold valve | Load Sensing Valves | |
| Hydraulic oil tank capacity | 18 L | |
| MAIN DIMENSION | ||
| Wheel base | 1500 mm | |
| Track length | 1860 mm | |
| Upper chassis ground clearance | 220 mm | |
| Counter weight turning radius | 670 mm | |
| Chassis width | 1300/1500 mm | |
| Track width | 230 mm | |
| Rotary table ground-off height | 520 mm | |
| Transportation length | 4100 mm | |
| Total height | 2440 mm | |
| OPERATINGRANGE | ||
| Max.digging radius on ground | 4520 mm | |
| Max.digging radius | 4400 mm | |
| Max.digging depth | 2410 mm | |
| Max.digging height | 4190 mm | |
| Max.dumping height | 2880 mm | |
| Maximum vertical digging depth | 1930 mm | |
| Minimum turning radius | 2130 mm | |
| Maximum Lift Of Dozer blade | 260 mm | |
| Maximum depth Of Dozer blade | 300 mm | |
Product Categories : Construction Machine And Truck > Excavator
