| Payment Type: | T/T,L/C |
|---|---|
| Incoterm: | FOB,CFR,CIF,EXW |
| Min. Order: | 1 Piece/Pieces |
Basic Info
Model No.: WP-S04
Brand: Wenpeng
Warranty Service: 1 Year
Place Of Origin: China
Additional Info
Packaging: exported packing
Productivity: 1000 pcs/month
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 1000 pcs/month
Certificate: CE/ISO
HS Code: 8428909090
Port: SHANGHAI
Payment Type: T/T,L/C
Incoterm: FOB,CFR,CIF,EXW
Product Description
| Model | S04 |
| Max. Working Height | 6.3 m |
| Max. Platform Height | 4.3 m |
| Overall Length | 1.42 m |
| Overall Width | 0.76 m |
| Overall Height(Rails Up) | 1.88 m |
| Overall Height(Rails folded) | 1.5m |
| Platform Dimention(Length×Width) | 1.42 x 0.76 m |
| Platform Extension dimention | 0.6 m |
| Wheelbase | 1.03 m |
| Ground Clearance(Stowed) | 60 mm |
| Ground Clearance(Raised) | 15 mm |
| Max. Working person | 2 |
| Rated load | 240 kg |
| Lift capacity - extension deck | 115 kg |
| Travel Speed(Stowed) | 4.0 km/h |
| Travel Speed(Raised) | 0.8 km/h |
| Raise/Lower time | 18/22 s |
| Gradeability-stowed | 25% |
| Turning Radius(Inside) | 0 |
| Turning Radius(Outside) | 1.38 m |
| Max. Working Slope | 3°/1.5° |
| Control | proportional |
| Driver | 2WD,precursor |
| Brake | 2rear wheel |
| Tyre Size | 255 x 76 mm |
| Battery | 24 V DC, 85 Ah |
| Charger | 90-240V 15Amp |
| Lifting Motor | 24V/1.2 kW |
| Driving Motor | 24V/0.4 kW |
| Hydrualic pump capacity | 5 L |
| Total weight | 895 kg |
Product Categories : Construction Machine And Truck > Aerial Work Platform
