Basic Info
Model No.: WP-V14D
Brand: Wenpeng
Warranty Service: 1 Year
After-sales Service: Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection
Place Of Origin: China
Additional Info
Packaging: exported packing
Productivity: 1000 pcs/month
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 1000 pcs/ month
Certificate: CE/ISO
HS Code: 8428909090
Port: QINGDAO
Payment Type: T/T,L/C
Incoterm: FOB,CFR,CIF,EXW
Product Description
| Model | V14D |
| Specifications | |
| Max. Working Height | 16m |
| Max. Platform Height | 14m |
| Max. Spanning Height | 7.4m |
| Max. Operating Radius | 8.22m |
| Platform Dimensions (L*W) | 1.4x0.76m |
| Length (Stowed) | 6.69m |
| Width (Stowed) | 2.26m |
| Height(Stowed) | 2.13m |
| Wheelbase | 2.10m |
| Ground Clearance | 0.41m |
| Weight | 6800kg |
| Productivity | |
| Max.Lift Capacity | 230kg |
| Platform Occupancy | 2 |
| Platform Rotation | 160° |
| Vertical Jib Rotation | ±70° |
| Turntable Rotation | 355 |
| Platform Leveling | Automatic leveling |
| Drive Speed (Stowed) | 5.5km/h |
| Drive Speed (Extended) | 0.8km/h |
| Drive Gradeability | 45% |
| Turning Radius (Inside) | ≤2.00m |
| Turning Radius (Outside) | 4.5m |
| Drive& Steer Mode | 4x2 |
| Tire Type | 33x12 |
| Power | |
| Engine | KUBOTA V2403 |
| Power | 36.5kw/2700rpm |
| Fuel Tank Volume | 150L |
| Control Voltage | 12V DC |
Product Categories : Construction Machine And Truck > Aerial Work Platform
