Basic Info
Model No.: HD16M
Brand: Wenpeng
Applicable Industry: Farms, Construction Works
Out-of-warranty Service: Video Technical Support, Online Support
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Place Of Origin: China
Status: New
Warranty Period: 1 Year
Additional Info
Productivity: 1000sets/month
Transportation: Ocean
Place of Origin: China
Supply Ability: 1000sets/month
Certificate: CE
Port: Qingdao
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Product Description
Load capacity: 16 Tons. Product complies with CE standards. 1 year warranty.
In addition, we also supply 180HP/220HP/240HP/260HP/320HP Crawler Bulldozers. Contact us for details and quotation.
| Model | HD16M |
|---|---|
| Dimension | 4990×3440×3110 mm |
| Weight | 16.4 T |
| Engine model | WP10G178E355 |
| Power (kw/r/min) | 131/1850 |
| Minimum fuel consumption g/KW.h | 214 |
| Grounding length (mm) | 2430 |
| Ground specific pressure (MPa) | 0.066 |
| Minimum ground clearance (mm) | 405 |
| Gradeability (°) | 30 |
| No. of track shoes (each side) | 37 |
| Width of Track shoe (mm) | 510(560.610) |
| Track Gauge (mm) | 1880 |
| Pitch (mm) | 203.2 |
| No of carrier rollers (each side) | 2 |
| No. of Track roller (each side) | 6 |
| Maximum traction force (KN) | 144 |
| Blade type | Straight-tilt Blade |
| Blade length x height (mm) | 3440×1149 |
| Blade Capacity (m³) | 4.5 |
| Blade lift height (mm) | 1095 |
| Blade depth (mm) | 540 |
| Maximum inclination of blade (mm) | 400 |
| Forward (km/h) | F1: 0 〜 2.67 F2: 0 〜 3.76 F3: 0 〜 5.41 F4: 0 〜 7.62 F5: 0 〜 11.13 |
| Reverse (km/h) | R1: 0 〜 3.48 R2: 0 〜 4.90 R3: 0 〜 7.05 R3: 0 〜 9.92 |
| Coolant capacity (L) | 79 |
| Fuel tank capacity (L) | 300 |
| Engine oil capacity (L) | 19 |
Product Categories : Construction Machine And Truck > Bulldozer
