| Payment Type: | L/C,T/T |
|---|---|
| Incoterm: | FOB,CFR,CIF,EXW |
| Min. Order: | 1 Set/Sets |
Basic Info
Model No.: EX240
Brand: Wenpeng
Applicable Industry: Building Material Shops, Farms, Construction Works, Energy &Amp; Mining, Other
Out-of-warranty Service: Video Technical Support, Online Support
Place Of Origin: China
Status: New
Exercise: Crawler Excavator
Warranty Period: 1 Year
Engine Brand: Cummins
Mechanical Test Report: Provided
Video Factory Inspection: Provided
Operating Mass: 24T
Bucket Capacity: 1.2-1.4m³
Additional Info
Productivity: 100set/month
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 100sets/month
Certificate: CE
Port: Qingdao
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Product Description
| Model | EX240 |
| Engine model | Cummins 6BTAA5.9 |
| Working mass | 24T |
| Bucket capacity(SAE) | 1.2-1.4m³ |
| Power | 133/2000kw/r/min |
| Volume of fuel tank | 350L |
| Travel speed (High/Low) | 5.69/3.86 km/h |
| Swing speed | 12.82 r/min |
| Gradeability | 35° |
| Digging force of bucket | 159KN |
| Digging force of stick | 115KN |
| Specific pressure of ground contact | 48.6Kpa |
| Traction | 174KN |
| Maximum flow | 226*2L/min |
| Working pressure | 34.3Mpa |
| Volume of hydraulic fluid tank | 246L |
| A-Overall length | 9740mm |
| B-Overall Width | 2980mm |
| C-Overall height(tope of boom) | 3190mm |
| D-Overall height(tope of cab) | 3120mm |
| E-Gap from counterweight to ground | 1065mm |
| F-Min ground clearance | 442mm |
| G-Tail swing radius | 2810mm |
| H-Length of track on ground | 3640mm |
| J-Track length | 4450mm |
| K-Gauge | 2380mm |
| L-Width of track | 2980mm |
| M-Width of track shoe | 600mm |
| N-Width of turning table | 2700mm |
| O-Max. digging height | 9310mm |
| P-Max. dumping height | 6438mm |
| Q-Max. digging depth | 6875mm |
| T-Max. digging distance | 10170mm |
| U-Max. digging distance at plane | 9990mm |
| Min. swing radius | 3975mm |
| Max height at min swing radius | 7775mm |
| Distance from center of swing to rear end | 2810mm |
| Y-Thickness of track grouses | 26mm |
| Height of counterweight | 2120mm |
| Ground Contact length (in transportation) | 5165mm |
| Length of stick | 3050mm |
| Length of boom | 5850mm |
